Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA.
Specifications:
| Description_ASM |
Chevrolet Small Block 350 |
| Description_DEF |
Engine Piston |
| Description_DES |
Piston Single, 4032, Flat Top, 4.040 Bore, 1.285 CD, 0.927 Pin, Set of 1. |
| Description_INV |
SRP, Piston |
| Description_EXT |
SRP, Chevrolet, Small Block Chevrolet, 4.040 in. Bore, 1.285 CD, Flat Top, Single Piston |
| Description_FAB |
- Forged in the USA using 4032 aluminum, yielding tensile strength and minimal thermal expansion
- Dedicated forging helps optimize strength and weight throughout the piston design
- Perfect for street/strip applications
- Forced pin oiling for improved pin lubrication
- Made 100% in the USA
|
| Description_SHO |
Piston |
| Description_MKT |
Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA. |
| Description_TLE |
Chevrolet 350, 4.040 Bore, Flat, Set of 1 |
| Piston Pin Outside Diameter |
0.927 |
| Bore Diameter |
4.040 |
| Prop 65 Yes/No |
Yes |
| Piston Volume |
-5.00 |
| Product Type |
Engine Piston |
| Wrist Pin Length |
2.750 |
| Prop 65 (C, R or CR) |
CR |
| Second Compression Ring Thickness |
0.0640 |
| Ring Set Included |
No |
| Industry |
Automotive |
| Title - Web |
SRP Chevrolet Small Block Piston - 4.040 in. Bore - 1.285 in. CH, -5.00 CC |
| Add-On |
927-2750-15-51S |
| Piston Material |
4032 |
| Cylinder Head |
CHEVROLET 23 DEG 20/30 |
| Add-On |
927-042-CS |
| Category Hierarchy |
Auto>SRP Pistons>SRP>Single Replacement Pistons |
| Compression Height |
1.285 |
| Add-On |
J100F8-4040-5 |
| Top Compression Ring Thickness |
0.0640 |
| Out of Stock Message |
Call for Availability |
| Product Market |
Domestic |
| Piston Average Weight |
455 |
| Make - Web |
Chevrolet |
| Engine - Web |
Small Block |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Title |
SRP - Chevrolet, Small Block, 4.040 in. Bore, Piston |
| Piston Head Type |
Flat |
| Piston Pin Length |
2.750 |
| Engine Type |
ICE |
| Engine |
Small Block |
| Oil Ring Thickness |
0.188 |
| Ringset Included |
No |
| Forging Type |
FSR |
| Piston Pin Wall Thickness |
0.150 |
| Piston Series |
SRP |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Wrist Pin Wall Thickness |
0.150 |
| Make |
CHEVROLET |
| Piston Pin Material |
5115 |
| Wrist Pin Outer Diameter |
0.927 |
| Length |
5.0000 |
| Width |
5.0000 |
| Height |
5.0000 |
| Weight |
1.0000 |
