Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA.
Specifications:
| Description_ASM |
Ford Small Block 351W Windsor |
| Description_DES |
Piston Set, 2618, Dome, 4.040 Bore, 1.774 CD, 0.912 Pin, Set of 8. |
| Description_DEF |
Engine Piston Kit |
| Description_FAB |
- Forged in the USA using 4032 aluminum, yielding tensile strength and minimal thermal expansion
- Dedicated forging helps optimize strength and weight throughout the piston design
- Perfect for street/strip applications
- Forced pin oiling for improved pin lubrication
- Made 100% in the USA
|
| Description_EXT |
SRP, Ford, Small Block Ford, 4.040 in. Bore, 1.774 CD, Dome, 8 Cyl. Piston Kit |
| Description_INV |
SRP, Piston Set |
| Description_TLE |
Ford 351 Windsor, 4.040 Bore, Dome, Set of 8 |
| Description_MKT |
Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA. |
| Description_SHO |
Piston Kit |
| Make |
FORD |
| Prop 65 (C, R or CR) |
CR |
| Prop 65 Yes/No |
Yes |
| Piston Pin Wall Thickness |
0.140 |
| Compression Height |
1.774 |
| Wrist Pin Outer Diameter |
0.912 |
| Engine - Web |
Small Block |
| Wrist Pin Length |
2.750 |
| Title |
SRP - Ford, Small Block, 4.040 in. Bore, Piston Kit |
| Industry |
Automotive |
| Category Hierarchy |
Auto>SRP Pistons>SRP>Piston Kits |
| Add-On |
927-042-CS |
| Piston Pin Outside Diameter |
0.912 |
| Product Market |
Domestic |
| Top Compression Ring Thickness |
0.0640 |
| Add-On |
S100S8-4040-5 |
| Piston Average Weight |
553 |
| Cylinder Head |
SMALL BLOCK FORD 20 DEG |
| Piston Volume |
10.00 |
| Bore Diameter |
4.040 |
| Add-On |
912-2750-14-51S |
| Product Type |
Engine Piston Kit |
| Ring Set Included |
No |
| Wrist Pin Wall Thickness |
0.140 |
| Title - Web |
SRP Ford Small Block Piston Kit - 4.040 in. Bore - 1.774 in. CH, 10.00 CC |
| Piston Pin Material |
5115 |
| Piston Head Type |
Dome |
| Engine |
Small Block |
| Second Compression Ring Thickness |
0.0640 |
| Engine Type |
ICE |
| Piston Material |
2618 |
| Forging Type |
FSR |
| Oil Ring Thickness |
0.188 |
| Piston Pin Length |
2.750 |
| Ringset Included |
No |
| Out of Stock Message |
Call for Availability |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Piston Series |
SRP |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Make - Web |
Ford |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
15.0000 |
