Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA.
Specifications:
| Description_ASM |
Ford Small Block 351W Windsor |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Dome, 4.030 Bore, 1.774 CD, 0.912 Pin, Set of 8. |
| Description_EXT |
SRP, Ford, Small Block Ford, 4.030 in. Bore, 1.774 CD, Dome, 8 Cyl. Piston Kit |
| Description_INV |
SRP, Piston Set |
| Description_FAB |
- Forged in the USA using 4032 aluminum, yielding tensile strength and minimal thermal expansion
- Dedicated forging helps optimize strength and weight throughout the piston design
- Perfect for street/strip applications
- Forced pin oiling for improved pin lubrication
- Made 100% in the USA
|
| Description_MKT |
Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA. |
| Description_SHO |
Piston Kit |
| Description_TLE |
Ford 351 Windsor, 4.030 Bore, Dome, Set of 8 |
| Make - Web |
Ford |
| Add-On |
912-2750-14-51S |
| Cylinder Head |
SMALL BLOCK FORD 20 DEG |
| Add-On |
927-042-CS |
| Add-On |
S100S8-4030-5 |
| Industry |
Automotive |
| Out of Stock Message |
Call for Availability |
| Piston Material |
2618 |
| Prop 65 Yes/No |
Yes |
| Prop 65 (C, R or CR) |
CR |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Second Compression Ring Thickness |
0.0640 |
| Ringset Included |
No |
| Piston Pin Length |
2.750 |
| Title - Web |
SRP Ford Small Block Piston Kit - 4.030 in. Bore - 1.774 in. CH, 10.00 CC |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Title |
SRP - Ford, Small Block, 4.030 in. Bore, Piston Kit |
| Oil Ring Thickness |
0.188 |
| Forging Type |
FSR |
| Engine Type |
ICE |
| Piston Pin Material |
5115 |
| Piston Series |
SRP |
| Piston Volume |
10.00 |
| Engine |
Small Block |
| Piston Pin Wall Thickness |
0.140 |
| Bore Diameter |
4.030 |
| Top Compression Ring Thickness |
0.0640 |
| Product Market |
Domestic |
| Wrist Pin Wall Thickness |
0.140 |
| Wrist Pin Outer Diameter |
0.912 |
| Ring Set Included |
No |
| Compression Height |
1.774 |
| Make |
FORD |
| Category Hierarchy |
Auto>SRP Pistons>SRP>Piston Kits |
| Piston Average Weight |
546 |
| Piston Pin Outside Diameter |
0.912 |
| Piston Head Type |
Dome |
| Product Type |
Engine Piston Kit |
| Wrist Pin Length |
2.750 |
| Engine - Web |
Small Block |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
15.0000 |
