Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA.
Specifications:
| Description_ASM |
Ford Pinto 2300 |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 4032, Flat Top, 3.810 Bore, 1.590 CD, 0.912 Pin, Set of 4. |
| Description_FAB |
- Forged in the USA using 4032 aluminum, yielding tensile strength and minimal thermal expansion
- Dedicated forging helps optimize strength and weight throughout the piston design
- Perfect for street/strip applications
- Forced pin oiling for improved pin lubrication
- Made 100% in the USA
|
| Description_EXT |
SRP, Ford, Pinto, 3.810 in. Bore, 1.590 CD, Flat Top, 4 Cyl. Piston Kit |
| Description_INV |
SRP, Piston Set |
| Description_MKT |
Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA. |
| Description_TLE |
Ford 2300 4-Cyl, 3.810 Bore, Flat, Set of 4 |
| Description_SHO |
Piston Kit |
| Oil Ring Thickness |
0.159 |
| Engine |
PINTO |
| Forging Type |
FSR |
| Engine Type |
ICE |
| Piston Pin Length |
2.500 |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Make - Web |
Ford |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Piston Series |
SRP |
| Ringset Included |
No |
| Title - Web |
SRP Ford Pin.to Piston Kit - 3.810 in. Bore - 1.590 in. CH, -1.00 CC |
| Piston Head Type |
Flat |
| Add-On |
927-042-CS |
| Prop 65 Yes/No |
Yes |
| Piston Average Weight |
412 |
| Bore Diameter |
3.810 |
| Make |
FORD |
| Prop 65 (C, R or CR) |
CR |
| Category Hierarchy |
Auto>SRP Pistons>SRP>Piston Kits |
| Second Compression Ring Thickness |
0.0600 |
| Add-On |
J64004-3810 |
| Out of Stock Message |
Call for Availability |
| Piston Material |
4032 |
| Title |
SRP - Ford, Pin.to, 3.810 in. Bore, Piston Kit |
| Piston Pin Wall Thickness |
0.140 |
| Compression Height |
1.590 |
| Add-On |
912-2500-14-51S |
| Piston Pin Outside Diameter |
0.912 |
| Top Compression Ring Thickness |
0.0600 |
| Piston Pin Material |
5115 |
| Product Type |
Engine Piston Kit |
| Product Market |
Domestic |
| Ring Set Included |
No |
| Wrist Pin Outer Diameter |
0.912 |
| Wrist Pin Wall Thickness |
0.140 |
| Wrist Pin Length |
2.500 |
| Cylinder Head |
PINTO |
| Industry |
Automotive |
| Piston Volume |
-1.00 |
| Engine - Web |
Pinto |
| Length |
5.0000 |
| Width |
9.0000 |
| Height |
5.0000 |
| Weight |
6.0000 |
