JE Pistons 148220S Piston Single, 4032, Flat Top, 3.830 Bore, 1.090 CD, 0.927 Pin, Set of 1.

2 sold in last 8 days
JE Pistons
ds_BHXG_148220S
Engine Piston
$264.44
customers are viewing this product
JE Pistons 170690L Piston Single, 2618, Flat Top, 4.040 Bore, 1.550 CD, 0.927 Pin, Set of 1.
JE Pistons 170690L Piston Single, 2618, Flat Top, 4.040 Bore, 1.550 CD, 0.927 Pin, Set of 1.
$321.46
JE Pistons 385324L Piston Single, 2618, Inv Dome/Dish, 4.090 Bore, 1.118 CD, 0.927 Pin Dia, 1 Ea.
JE Pistons 385324L Piston Single, 2618, Inv Dome/Dish, 4.090 Bore, 1.118 CD, 0.927 Pin Dia, 1 Ea.
$273.69
JE Pistons 148220S Piston Single, 4032, Flat Top, 3.830 Bore, 1.090 CD, 0.927 Pin, Set of 1.
Details

Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA.

Specifications:

Description_ASM Ford Pinto 2300
Description_DEF Engine Piston
Description_DES Piston Single, 4032, Flat Top, 3.830 Bore, 1.090 CD, 0.927 Pin, Set of 1.
Description_INV SRP, Piston
Description_EXT SRP, Ford, Pinto, 3.830 in. Bore, 1.090 CD, Flat Top, Single Piston
Description_FAB
  • Forged in the USA using 4032 aluminum, yielding tensile strength and minimal thermal expansion
  • Dedicated forging helps optimize strength and weight throughout the piston design
  • Perfect for street/strip applications
  • Forced pin oiling for improved pin lubrication
  • Made 100% in the USA
Description_SHO Piston
Description_MKT Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA.
Description_TLE Ford 2300 4-Cyl, 3.830 Bore, Flat, Set of 1
Make - Web Ford
Second Compression Ring Thickness 0.0600
Piston Pin Length 2.500
Prop 65 Yes/No Yes
Wrist Pin Material 5115 Low Carbon Steel, Case Hardened
Prop 65 - Short Label Prop 65 Warning Label.JPG
Piston Series SRP
Out of Stock Message Call for Availability
Engine PINTO
Title - Web SRP Ford Pin.to Piston - 3.830 in. Bore - 1.090 in. CH, -1.00 CC
Engine Type ICE
Ringset Included No
Oil Ring Thickness 0.188
Piston Head Type Flat
Add-On 927-2500-13-51S
Piston Pin Outside Diameter 0.927
Forging Type FSR
Cylinder Head PINTO
Bore Diameter 3.830
Title SRP - Ford, Pin.to, 3.830 in. Bore, Piston
Add-On 927-042-CS
Piston Pin Material 5115
Category Hierarchy Auto>SRP Pistons>SRP>Single Replacement Pistons
Make FORD
Product Type Engine Piston
Product Market Domestic
Add-On J616F4-3830
Piston Average Weight 344
Industry Automotive
Top Compression Ring Thickness 0.0600
Wrist Pin Wall Thickness 0.130
Wrist Pin Length 2.500
Ring Set Included No
Engine - Web Pinto
Wrist Pin Outer Diameter 0.927
Piston Volume -1.00
Compression Height 1.090
Piston Material 4032
Prop 65 (C, R or CR) CR
Piston Pin Wall Thickness 0.130
Length 5.0000
Width 5.0000
Height 5.0000
Weight 1.0000
