Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA.
Specifications:
| Description_ASM |
Chevrolet Big Block 454 |
| Description_DES |
Piston Set, 4032, Dome, 4.280 Bore, 1.270 CD, 0.990 Pin, Set of 8. |
| Description_DEF |
Engine Piston Kit |
| Description_EXT |
SRP, Chevrolet, Big Block Chevrolet, 4.280 in. Bore, 1.270 CD, Dome, 8 Cyl. Piston Kit |
| Description_INV |
SRP, Piston Set |
| Description_FAB |
- Forged in the USA using 4032 aluminum, yielding tensile strength and minimal thermal expansion
- Dedicated forging helps optimize strength and weight throughout the piston design
- Perfect for street/strip applications
- Forced pin oiling for improved pin lubrication
- Made 100% in the USA
|
| Description_SHO |
Piston Kit |
| Description_MKT |
Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA. |
| Description_TLE |
Chevrolet 454, 4.280 Bore, Dome, Set of 8 |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Ringset Included |
No |
| Title - Web |
SRP Chevrolet Big Block Piston Kit - 4.280 in. Bore - 1.270 in. CH, 5.00 CC |
| Cylinder Head |
CLOSED CHMBR |
| Piston Pin Length |
2.930 |
| Make - Web |
Chevrolet |
| Out of Stock Message |
Call for Availability |
| Prop 65 Yes/No |
Yes |
| Add-On |
990-042-CS |
| Engine |
Big Block |
| Second Compression Ring Thickness |
0.0800 |
| Add-On |
990-2930-15-51S |
| Piston Head Type |
Dome |
| Add-On |
JE00F8-4280-0 |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Title |
SRP - Chevrolet, Big Block, 4.280 in. Bore, Piston Kit |
| Forging Type |
FSR |
| Make |
CHEVROLET |
| Product Type |
Engine Piston Kit |
| Product Market |
Domestic |
| Engine Type |
ICE |
| Oil Ring Thickness |
0.218 |
| Piston Series |
SRP |
| Industry |
Automotive |
| Piston Volume |
5.00 |
| Piston Pin Wall Thickness |
0.150 |
| Piston Average Weight |
542 |
| Piston Pin Material |
5115 |
| Compression Height |
1.270 |
| Piston Pin Outside Diameter |
0.990 |
| Engine - Web |
Big Block |
| Wrist Pin Outer Diameter |
0.990 |
| Wrist Pin Length |
2.930 |
| Wrist Pin Wall Thickness |
0.150 |
| Ring Set Included |
No |
| Piston Material |
4032 |
| Prop 65 (C, R or CR) |
CR |
| Category Hierarchy |
Auto>SRP Pistons>SRP>Piston Kits |
| Bore Diameter |
4.280 |
| Top Compression Ring Thickness |
0.0800 |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
15.0000 |
