Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA.
Specifications:
| Description_ASM |
Chevrolet Small Block 400 |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Dome, 4.155 Bore, 1.125 CD, 0.927 Pin, Set of 8. |
| Description_FAB |
- Forged in the USA using 4032 aluminum, yielding tensile strength and minimal thermal expansion
- Dedicated forging helps optimize strength and weight throughout the piston design
- Perfect for street/strip applications
- Forced pin oiling for improved pin lubrication
- Made 100% in the USA
|
| Description_EXT |
SRP, Chevrolet, Small Block Chevrolet, 4.155 in. Bore, 1.125 CD, Dome, 8 Cyl. Piston Kit |
| Description_INV |
SRP, Piston Set |
| Description_MKT |
Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA. |
| Description_TLE |
Chevrolet 400, 4.155 Bore, Dome, Set of 8 |
| Description_SHO |
Piston Kit |
| Bore Diameter |
4.155 |
| Product Market |
Domestic |
| Ring Set Included |
No |
| Piston Average Weight |
449 |
| Top Compression Ring Thickness |
0.0640 |
| Cylinder Head |
CHEVROLET 23 DEG 20/30 |
| Wrist Pin Outer Diameter |
0.927 |
| Compression Height |
1.125 |
| Category Hierarchy |
Auto>SRP Pistons>SRP>Piston Kits |
| Piston Pin Outside Diameter |
0.927 |
| Title |
SRP - Chevrolet, Small Block, 4.155 in. Bore, Piston Kit |
| Piston Pin Wall Thickness |
0.150 |
| Product Type |
Engine Piston Kit |
| Piston Material |
2618 |
| Engine - Web |
Small Block |
| Make |
CHEVROLET |
| Add-On |
927-042-CS |
| Industry |
Automotive |
| Prop 65 Yes/No |
Yes |
| Prop 65 (C, R or CR) |
CR |
| Add-On |
S100S8-4155-5 |
| Add-On |
927-2750-15-51S |
| Piston Volume |
4.00 |
| Out of Stock Message |
Call for Availability |
| Wrist Pin Length |
2.750 |
| Title - Web |
SRP Chevrolet Small Block Piston Kit - 4.155 in. Bore - 1.125 in. CH, 4.00 CC |
| Forging Type |
FSR |
| Piston Pin Material |
5115 |
| Engine |
Small Block |
| Piston Series |
SRP |
| Oil Ring Thickness |
0.218 |
| Piston Head Type |
Dome |
| Ringset Included |
No |
| Second Compression Ring Thickness |
0.0640 |
| Piston Pin Length |
2.750 |
| Engine Type |
ICE |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Make - Web |
Chevrolet |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Wrist Pin Wall Thickness |
0.150 |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
14.0000 |
