Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA.
Specifications:
Description_ASM |
Chevrolet Big Block 454 |
Description_DEF |
Engine Piston |
Description_DES |
Piston Single, 2618, Dome, 4.350 Bore, 1.245 CD, 0.990 Pin, Set of 1. |
Description_FAB |
- Forged in the USA using 4032 aluminum, yielding tensile strength and minimal thermal expansion
- Dedicated forging helps optimize strength and weight throughout the piston design
- Perfect for street/strip applications
- Forced pin oiling for improved pin lubrication
- Made 100% in the USA
|
Description_EXT |
SRP, Chevrolet, Big Block Chevrolet, 4.350 in. Bore, 1.245 CD, Dome, Single Piston |
Description_INV |
SRP, Piston |
Description_MKT |
Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA. |
Description_SHO |
Piston |
Description_TLE |
Chevrolet 454, 4.350 Bore, Dome, Set of 1 |
Piston Pin Wall Thickness |
0.150 |
Prop 65 Yes/No |
Yes |
Wrist Pin Outer Diameter |
0.990 |
Prop 65 (C, R or CR) |
CR |
Piston Pin Outside Diameter |
0.990 |
Wrist Pin Length |
2.930 |
Piston Volume |
48.00 |
Add-On |
S100S8-4350-5 |
Out of Stock Message |
Call for Availability |
Piston Average Weight |
625 |
Piston Material |
2618 |
Compression Height |
1.245 |
Add-On |
990-2930-15-51S |
Category Hierarchy |
Auto>SRP Pistons>SRP>Single Replacement Pistons |
Product Type |
Engine Piston |
Make |
CHEVROLET |
Bore Diameter |
4.350 |
Industry |
Automotive |
Title |
SRP - Chevrolet, Big Block, 4.350 in. Bore, Piston |
Top Compression Ring Thickness |
0.0640 |
Add-On |
990-042-CS |
Product Market |
Domestic |
Cylinder Head |
OPEN CHAMBER |
Wrist Pin Wall Thickness |
0.150 |
Engine - Web |
Big Block |
Ring Set Included |
No |
Piston Series |
SRP |
Piston Pin Material |
5115 |
Ringset Included |
No |
Forging Type |
FSR |
Title - Web |
SRP Chevrolet Big Block Piston - 4.350 in. Bore - 1.245 in. CH, 48.00 CC |
Engine Type |
ICE |
Second Compression Ring Thickness |
0.0640 |
Piston Head Type |
Dome |
Piston Pin Length |
2.930 |
Engine |
Big Block |
Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
Make - Web |
Chevrolet |
Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
Oil Ring Thickness |
0.218 |
Length |
5.0000 |
Width |
5.0000 |
Height |
5.0000 |
Weight |
2.0000 |
