Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA.
Specifications:
| Description_ASM |
Chevrolet Small Block 350 |
| Description_DES |
Piston Set, 4032, Inv Dome/Dish, 4.030 Bore, 1.560 CD, 0.927 Pin, Set of 8. |
| Description_DEF |
Engine Piston Kit |
| Description_INV |
SRP, Piston Set |
| Description_EXT |
SRP, Chevrolet, Small Block Chevrolet, 4.030 in. Bore, 1.560 CD, Inverted Dome/Dish, 8 Cyl. Piston Kit |
| Description_FAB |
- Forged in the USA using 4032 aluminum, yielding tensile strength and minimal thermal expansion
- Dedicated forging helps optimize strength and weight throughout the piston design
- Perfect for street/strip applications
- Forced pin oiling for improved pin lubrication
- Made 100% in the USA
|
| Description_TLE |
Chevrolet 350, 4.030 Bore, Dish, Set of 8 |
| Description_SHO |
Piston Kit |
| Description_MKT |
Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA. |
| Piston Series |
SRP |
| Product Market |
Domestic |
| Wrist Pin Outer Diameter |
0.927 |
| Wrist Pin Wall Thickness |
0.150 |
| Piston Pin Material |
5115 |
| Forging Type |
FSR |
| Make |
CHEVROLET |
| Engine Type |
ICE |
| Product Type |
Engine Piston Kit |
| Wrist Pin Length |
2.750 |
| Ring Set Included |
No |
| Title |
SRP - Chevrolet, Small Block, 4.030 in. Bore, Piston Kit |
| Piston Material |
4032 |
| Bore Diameter |
4.030 |
| Piston Pin Outside Diameter |
0.927 |
| Top Compression Ring Thickness |
0.0640 |
| Piston Average Weight |
501 |
| Piston Volume |
-24.00 |
| Piston Pin Wall Thickness |
0.150 |
| Compression Height |
1.560 |
| Category Hierarchy |
Auto>SRP Pistons>SRP>Piston Kits |
| Engine - Web |
Small Block |
| Cylinder Head |
CHEVROLET 23 DEG 20/30 |
| Prop 65 (C, R or CR) |
CR |
| Prop 65 Yes/No |
Yes |
| Engine |
Small Block |
| Second Compression Ring Thickness |
0.0640 |
| Oil Ring Thickness |
0.188 |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Make - Web |
Chevrolet |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Industry |
Automotive |
| Add-On |
927-042-CS |
| Add-On |
S100S8-4030-5 |
| Out of Stock Message |
Call for Availability |
| Piston Head Type |
Dish |
| Add-On |
927-2750-15-51S |
| Piston Pin Length |
2.750 |
| Ringset Included |
No |
| Title - Web |
SRP Chevrolet Small Block Piston Kit - 4.030 in. Bore - 1.560 in. CH, -24.00 CC |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
12.0000 |
