Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA.
Specifications:
| Description_ASM |
Ford Small Block 351W Windsor |
| Description_DES |
Piston Set, 4032, Flat Top, 4.060 Bore, 1.774 CD, 0.912 Pin, Set of 8. |
| Description_DEF |
Engine Piston Kit |
| Description_FAB |
- Forged in the USA using 4032 aluminum, yielding tensile strength and minimal thermal expansion
- Dedicated forging helps optimize strength and weight throughout the piston design
- Perfect for street/strip applications
- Forced pin oiling for improved pin lubrication
- Made 100% in the USA
|
| Description_INV |
SRP, Piston Set |
| Description_EXT |
SRP, Ford, Small Block Ford, 4.060 in. Bore, 1.774 CD, Flat Top, 8 Cyl. Piston Kit |
| Description_TLE |
Ford 351 Windsor, 4.060 Bore, Flat, Set of 8 |
| Description_MKT |
Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA. |
| Description_SHO |
Piston Kit |
| Industry |
Automotive |
| Cylinder Head |
SMALL BLOCK FORD 20 DEG |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Second Compression Ring Thickness |
0.0640 |
| Prop 65 (C, R or CR) |
CR |
| Piston Material |
4032 |
| Make - Web |
Ford |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Title - Web |
SRP Ford Small Block Piston Kit - 4.060 in. Bore - 1.774 in. CH, -5.00 CC |
| Ringset Included |
No |
| Add-On |
S100S8-4060-5 |
| Piston Head Type |
Flat |
| Engine |
Small Block |
| Piston Pin Length |
2.750 |
| Out of Stock Message |
Call for Availability |
| Prop 65 Yes/No |
Yes |
| Add-On |
927-042-CS |
| Add-On |
912-2750-14-51S |
| Piston Pin Wall Thickness |
0.140 |
| Piston Pin Material |
5115 |
| Bore Diameter |
4.060 |
| Piston Volume |
-5.00 |
| Oil Ring Thickness |
0.188 |
| Category Hierarchy |
Auto>SRP Pistons>SRP>Piston Kits |
| Compression Height |
1.774 |
| Product Type |
Engine Piston Kit |
| Forging Type |
FSR |
| Title |
SRP - Ford, Small Block, 4.060 in. Bore, Piston Kit |
| Top Compression Ring Thickness |
0.0640 |
| Engine Type |
ICE |
| Piston Average Weight |
552 |
| Piston Series |
SRP |
| Piston Pin Outside Diameter |
0.912 |
| Make |
FORD |
| Product Market |
Domestic |
| Wrist Pin Outer Diameter |
0.912 |
| Engine - Web |
Small Block |
| Wrist Pin Wall Thickness |
0.140 |
| Wrist Pin Length |
2.750 |
| Ring Set Included |
No |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
12.0000 |
