Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA.
Specifications:
| Description_ASM |
Ford Small Block 351W Windsor |
| Description_DEF |
Engine Piston |
| Description_DES |
Piston Single, 4032, Flat Top, 4.020 Bore, 1.774 CD, 0.912 Pin, Set of 1. |
| Description_INV |
SRP, Piston |
| Description_EXT |
SRP, Ford, Small Block Ford, 4.020 in. Bore, 1.774 CD, Flat Top, Single Piston |
| Description_FAB |
- Forged in the USA using 4032 aluminum, yielding tensile strength and minimal thermal expansion
- Dedicated forging helps optimize strength and weight throughout the piston design
- Perfect for street/strip applications
- Forced pin oiling for improved pin lubrication
- Made 100% in the USA
|
| Description_SHO |
Piston |
| Description_MKT |
Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA. |
| Description_TLE |
Ford 351 Windsor, 4.020 Bore, Flat, Set of 1 |
| Piston Average Weight |
530 |
| Ringset Included |
No |
| Engine |
Small Block |
| Engine Type |
ICE |
| Piston Pin Material |
5115 |
| Forging Type |
FSR |
| Piston Series |
SRP |
| Product Market |
Domestic |
| Wrist Pin Wall Thickness |
0.140 |
| Piston Head Type |
Flat |
| Piston Pin Outside Diameter |
0.912 |
| Compression Height |
1.774 |
| Top Compression Ring Thickness |
0.0640 |
| Bore Diameter |
4.020 |
| Oil Ring Thickness |
0.188 |
| Title |
SRP - Ford, Small Block, 4.020 in. Bore, Piston |
| Piston Pin Wall Thickness |
0.140 |
| Make |
FORD |
| Engine - Web |
Small Block |
| Wrist Pin Outer Diameter |
0.912 |
| Add-On |
927-042-CS |
| Product Type |
Engine Piston |
| Piston Material |
4032 |
| Category Hierarchy |
Auto>SRP Pistons>SRP>Single Replacement Pistons |
| Add-On |
912-2750-14-51S |
| Second Compression Ring Thickness |
0.0640 |
| Prop 65 (C, R or CR) |
CR |
| Piston Pin Length |
2.750 |
| Industry |
Automotive |
| Cylinder Head |
SMALL BLOCK FORD 20 DEG |
| Piston Volume |
-5.00 |
| Prop 65 Yes/No |
Yes |
| Out of Stock Message |
Call for Availability |
| Add-On |
S100S8-4020-5 |
| Title - Web |
SRP Ford Small Block Piston - 4.020 in. Bore - 1.774 in. CH, -5.00 CC |
| Make - Web |
Ford |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Ring Set Included |
No |
| Wrist Pin Length |
2.750 |
| Length |
5.0000 |
| Width |
5.0000 |
| Height |
5.0000 |
| Weight |
1.0000 |
