Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA.
Specifications:
| Description_ASM |
Ford Small Block 289/302 |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 4032, Inv Dome/Dish, 4.060 Bore, 1.600 CD, 0.912 Pin, Set of 8. |
| Description_INV |
SRP, Piston Set |
| Description_EXT |
SRP, Ford, Small Block Ford, 4.060 in. Bore, 1.600 CD, Inverted Dome/Dish, 8 Cyl. Piston Kit |
| Description_FAB |
- Forged in the USA using 4032 aluminum, yielding tensile strength and minimal thermal expansion
- Dedicated forging helps optimize strength and weight throughout the piston design
- Perfect for street/strip applications
- Forced pin oiling for improved pin lubrication
- Made 100% in the USA
|
| Description_SHO |
Piston Kit |
| Description_MKT |
Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA. |
| Description_TLE |
Ford 289/302, 4.060 Bore, Dish, Set of 8 |
| Add-On |
927-042-CS |
| Add-On |
S100S8-4060-5 |
| Add-On |
912-2750-14-51S |
| Prop 65 (C, R or CR) |
CR |
| Industry |
Automotive |
| Piston Volume |
-14.50 |
| Piston Pin Length |
2.750 |
| Ring Set Included |
No |
| Product Type |
Engine Piston Kit |
| Engine |
Small Block |
| Wrist Pin Length |
2.750 |
| Piston Material |
4032 |
| Prop 65 Yes/No |
Yes |
| Out of Stock Message |
Call for Availability |
| Title - Web |
SRP Ford Small Block Piston Kit - 4.060 in. Bore - 1.600 in. CH, -14.50 CC |
| Second Compression Ring Thickness |
0.0640 |
| Cylinder Head |
SMALL BLOCK FORD 20 DEG |
| Make - Web |
Ford |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Piston Pin Outside Diameter |
0.912 |
| Make |
FORD |
| Forging Type |
FSR |
| Bore Diameter |
4.060 |
| Product Market |
Domestic |
| Piston Pin Material |
5115 |
| Title |
SRP - Ford, Small Block, 4.060 in. Bore, Piston Kit |
| Ringset Included |
No |
| Piston Average Weight |
512 |
| Piston Series |
SRP |
| Piston Head Type |
Dish |
| Category Hierarchy |
Auto>SRP Pistons>SRP>Piston Kits |
| Engine Type |
ICE |
| Piston Pin Wall Thickness |
0.140 |
| Oil Ring Thickness |
0.188 |
| Top Compression Ring Thickness |
0.0640 |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Engine - Web |
Small Block |
| Wrist Pin Wall Thickness |
0.140 |
| Wrist Pin Outer Diameter |
0.912 |
| Compression Height |
1.600 |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
14.0000 |
