Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA.
Specifications:
| Description_ASM |
Ford Small Block 289/302 |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 4032, Inv Dome/Dish, 4.040 Bore, 1.600 CD, 0.912 Pin, Set of 8. |
| Description_FAB |
- Forged in the USA using 4032 aluminum, yielding tensile strength and minimal thermal expansion
- Dedicated forging helps optimize strength and weight throughout the piston design
- Perfect for street/strip applications
- Forced pin oiling for improved pin lubrication
- Made 100% in the USA
|
| Description_INV |
SRP, Piston Set |
| Description_EXT |
SRP, Ford, Small Block Ford, 4.040 in. Bore, 1.600 CD, Inverted Dome/Dish, 8 Cyl. Piston Kit |
| Description_TLE |
Ford 289/302, 4.040 Bore, Dish, Set of 8 |
| Description_MKT |
Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA. |
| Description_SHO |
Piston Kit |
| Oil Ring Thickness |
0.188 |
| Engine Type |
ICE |
| Category Hierarchy |
Auto>SRP Pistons>SRP>Piston Kits |
| Product Market |
Domestic |
| Ringset Included |
No |
| Forging Type |
FSR |
| Bore Diameter |
4.040 |
| Piston Series |
SRP |
| Top Compression Ring Thickness |
0.0640 |
| Compression Height |
1.600 |
| Piston Pin Material |
5115 |
| Title |
SRP - Ford, Small Block, 4.040 in. Bore, Piston Kit |
| Piston Pin Wall Thickness |
0.140 |
| Piston Pin Outside Diameter |
0.912 |
| Piston Head Type |
Dish |
| Make |
FORD |
| Piston Average Weight |
501 |
| Wrist Pin Length |
2.750 |
| Wrist Pin Wall Thickness |
0.140 |
| Wrist Pin Outer Diameter |
0.912 |
| Engine - Web |
Small Block |
| Add-On |
S100S8-4040-5 |
| Piston Material |
4032 |
| Prop 65 Yes/No |
Yes |
| Engine |
Small Block |
| Piston Pin Length |
2.750 |
| Piston Volume |
-14.50 |
| Add-On |
912-2750-14-51S |
| Add-On |
927-042-CS |
| Industry |
Automotive |
| Title - Web |
SRP Ford Small Block Piston Kit - 4.040 in. Bore - 1.600 in. CH, -14.50 CC |
| Out of Stock Message |
Call for Availability |
| Cylinder Head |
SMALL BLOCK FORD 20 DEG |
| Prop 65 (C, R or CR) |
CR |
| Second Compression Ring Thickness |
0.0640 |
| Product Type |
Engine Piston Kit |
| Make - Web |
Ford |
| Ring Set Included |
No |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
14.0000 |
