Edelbrock part #7176 Performer RPM intake manifold is designed for 340-360 c.i.d. Chrysler V8's and 318 c.i.d. engines with 340-360 cylinder heads. Latest technology in dual-plane design results in both excellent low-rpm torque and outstanding high rpm horsepower. Recommended for high-performance street, strip and fresh water marine applications. Accepts 1975 and earlier waterneck only. Will not accept stock Thermo-Quad carburetor. Will not fit 1992 and later Magnum engines. Match with Performer RPM heads #60779 for maximum performance.
Specifications:
| Description_ABR |
Intake Mnfld |
| Description_ASM |
Chrysler:Small-Block:273 (4.5L)/318 (5.2L)/340 (5.6L)/360 (5.9L) |
| Description_DEF |
Engine Intake Manifold |
| Description_LAB |
Performer RPM Small Block Chrysler Intake Manifold |
| Description_EXT |
Edelbrock Performer Intake Manifold for 318-340-360 Chrysler Small Block LA engines |
| Description_INV |
Performer RPM 360 Chrysler Intake Mnfld |
| Description_TRA |
Recommended intake gasket: Edelbrock #7276, Fel-Pro #1213, Chrysler #4397642 (or equivalent) for 340 & 360. |
| Description_TRA |
Manifold height: A-4.9", B-5.8" |
| Description_TRA |
Carb pad height: 5.35" |
| Description_TRA |
Carb recommendations: Edelbrock AVS2 or Performer Series 650-800 cfm. Use #1481 or #1843 throttle/transmission lever kit. |
| Description_TRA |
Port exit dimensions: 1.01" x 2.17" |
| Description_TRA |
1979 and later rotary A/C compressor will not clear waterneck |
| Description_TRA |
Use RTV sealant to properly seal end seals, such as Edelbrock High Temp Silicone sealant #1076, DO NOT USE END SEALS GASKETS. |
| Description_TRA |
Hardened washers Must be used with intake bolts to ensure proper torque and prevent galling of the aluminum. |
| Description_MKT |
Edelbrock part #7176 Performer RPM intake manifold is designed for 340-360 c.i.d. Chrysler V8's and 318 c.i.d. engines with 340-360 cylinder heads. Latest technology in dual-plane design results in both excellent low-rpm torque and outstanding high rpm horsepower. Recommended for high-performance street, strip and fresh water marine applications. Accepts 1975 and earlier waterneck only. Will not accept stock Thermo-Quad carburetor. Will not fit 1992 and later Magnum engines. Match with Performer RPM heads #60779 for maximum performance. |
| Center Maximum Height |
5.350 |
| Gasket Or Seal Included |
No |
| Basic Operating RPM Range |
1500-6500 |
| Front Maximum Height |
4.900 |
| Vehicle Model |
Chrysler |
| EGR Port |
No |
| Finish |
Satin |
| Flange Type |
4150 |
| RGL |
WARNING: This product can expose you to Lead, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov. |
| CNC Ported |
No |
| Grade Type |
Performance |
| Series |
Performer RPM |
| Single Or Dual Plane Type |
Dual |
| Material |
Aluminum |
| Rear Maximum Height |
5.800 |
| Length |
8.0000 |
| Width |
15.0000 |
| Height |
24.0000 |
| Weight |
21.0000 |
