Edelbrock part #29021 Victor Jr. 454-R intake manifold is designed for competition 396-502 big-block Chevys with rectangular-port heads. This intake is designed to optimize the flow characteristics of an 850 cfm standard flange carb. Features include extended runner dividers, smaller plenum chambers and unique runner design for better 60 foot times and max power from 3500 to 7500 rpm. This manifold is especially suited to 502 c.i.d. and smaller competition engines. The Victor Jr. 454-R will fit Edelbrock Victor race heads #77609 and Victor 24-degree #77409, #77459, #77429, #77479 and #77485. This manifold offers a polished finish for a brilliant shine and classic look.
Specifications:
| Description_ABR |
Intake Mnfld |
| Description_ASM |
Chevrolet:Big-Block Mark IV:396 (6.6L)/402 (6.6L)/427 (7.0L)/454 (7.4L)/502 (8.2L) |
| Description_DEF |
Engine Intake Manifold |
| Description_EXT |
Edelbrock Victor Jr. 454-R Intake Manifold For Chevrolet 396-502 Big-Block V8 |
| Description_INV |
Polished Victor Jr BBC Rectangular Port |
| Description_LAB |
Victor Jr. Big Block Chevy 454-R Intake Manifold |
| Description_MKT |
Edelbrock part #29021 Victor Jr. 454-R intake manifold is designed for competition 396-502 big-block Chevys with rectangular-port heads. This intake is designed to optimize the flow characteristics of an 850 cfm standard flange carb. Features include extended runner dividers, smaller plenum chambers and unique runner design for better 60 foot times and max power from 3500 to 7500 rpm. This manifold is especially suited to 502 c.i.d. and smaller competition engines. The Victor Jr. 454-R will fit Edelbrock Victor race heads #77609 and Victor 24-degree #77409, #77459, #77429, #77479 and #77485. This manifold offers a polished finish for a brilliant shine and classic look. |
| Description_TRA |
Recommended intake gasket: Edelbrock #7208 |
| Description_TRA |
Manifold height: A-5.90" & B-5.90" |
| Description_TRA |
Carb recommendations: Use appropriate racing carburetor |
| Description_TRA |
Use RTV sealant to properly seal end seals, such as Edelbrock High Temp Silicone sealant #1076, DO NOT USE END SEALS GASKETS. |
| Description_TRA |
Hardened washers Must be used with intake bolts to ensure proper torque and prevent galling of the aluminum. |
| EGR Port |
No |
| Finish |
Polished |
| Basic Operating RPM Range |
3500-7500 |
| Rear Maximum Height |
5.960 |
| Single Or Dual Plane Type |
Single |
| Material |
Aluminum |
| Grade Type |
Performance |
| Flange Type |
4150 |
| Series |
Victor |
| CNC Ported |
No |
| Center Maximum Height |
5.960 |
| Vehicle Model |
Chevrolet |
| Front Maximum Height |
5.960 |
| Gasket Or Seal Included |
No |
| RGL |
WARNING: This product can expose you to Lead, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov. |
| Length |
8.0000 |
| Width |
15.0000 |
| Height |
24.0000 |
| Weight |
21.0000 |
