K1 Technologies connecting rods are manufactured with optimized strength and weight characteristics in mind to deliver reliable performance. Forged from 4340 steel, K1 rods featured a shot-peened surface finish which smooths surface blends and reduces potential stress profiles. K1 connecting rods are held to strict quality standards and undergo magnetic particle testing to ensure material properties are free of flaws. Each rod is also subject to bore tolerance compliance, holding them to +/- .0001 after finishing. Additionally, K1 rods are balanced and tested to be within +/- 1 gram per end. A dual-ribbing design on the rod caps of K1 connecting rods helps maximize strength and allows the rod big end to maintain roundness as engine RPMs increase. Full-floating, precision-honed bronze bushings are fixed into the small ends of the rods for low friction and high wear resistance. Fitted with ARP 2000 rod bolts rated at 200,000 psi tensile strength for most applications, K1 connecting rods deliver an industry-leading combination of strength and value.
Specifications:
Description_ASM |
Chrysler 5.7 / 6.1L Hemi |
Description_DEF |
Engine Connecting Rod Set |
Description_DES |
Connecting Rod Set, Chrysler 5.7 / 6.1L Hemi, 6.243 in. Length, H-Beam, Set of 8 |
Description_EXT |
K1 Technologies Chrysler 5.7 / 6.1L Hemi Connecting Rod Set, 6.243 in. Length, 0.927 in. Pin, 2.250 in. Journal, 7/16 in. ARP 2000 Bolts, Forged 4340 Steel, H-Beam, Set of 8. |
Description_MKT |
K1 Technologies connecting rods are manufactured with optimized strength and weight characteristics in mind to deliver reliable performance. Forged from 4340 steel, K1 rods featured a shot-peened surface finish which smooths surface blends and reduces potential stress profiles. K1 connecting rods are held to strict quality standards and undergo magnetic particle testing to ensure material properties are free of flaws. Each rod is also subject to bore tolerance compliance, holding them to +/- .0001? after finishing. Additionally, K1 rods are balanced and tested to be within +/- 1 gram per end. A dual-ribbing design on the rod caps of K1 connecting rods helps maximize strength and allows the rod big end to maintain roundness as engine RPMs increase. Full-floating, precision-honed bronze bushings are fixed into the small ends of the rods for low friction and high wear resistance. Fitted with ARP 2000 rod bolts rated at 200,000 psi tensile strength for most applications, K1 connecting rods deliver an industry-leading combination of strength and value. |
Description_INV |
K1 Technologies, Connecting Rod Set |
Description_FAB |
4340 Forged Steel for strength, toughness, and resistance to impact ~ High quality ARP 2000 fasteners included ~ All rods are finished in the USA and held to very tight tolerences Bores finished to +/- .0001 in. and weight to +/- 1 gram per end ~ Shot peened for improved fatigue life ~ Premium bronze wrist pin bushings ~ Designed by in-house engineering team for high-stress racing applications |
Description_SHO |
Connecting Rod Set |
Description_TLE |
Chrysler, 5.7 / 6.1L Hemi, 6.243 in. Length, Connecting Rod Set |
Add-On |
BT71601-S |
Average Gram Weight |
622 |
Bolt Diameter |
7/16 |
Bolt Part Number |
BT71601-S |
Category Hierarchy |
Connecting Rods>Connecting Rod Kits>Domestic>Chrysler |
Center To Center Length |
6.243 |
Connecting Rod Finish |
Shot-peened |
Engine |
Small Block Hemi |
Industry |
Automotive |
Lightened |
No |
Main Bearing Bore Diameter |
2.252 |
Main Bearing Width |
0.934 |
Make |
Chrysler |
Material |
Forged 4340 Steel |
Mounting Hardware Included |
Yes |
Out of Stock Message |
Call for Availability |
Pin End Bore |
0.927 |
Engine - Web |
Small Block Hemi |
Make - Web |
Chrysler |
Product Market |
Domestic |
Product Type |
Engine Connecting Rod Set |
Prop 65 - Short Label |
prop65_warning.jpg |
Prop 65 (C, R or CR) |
CR |
Prop 65 Yes/No |
Yes |
Rod Quantity |
8 |
Rod Type |
H-Beam |
Title |
Chrysler, 5.7 / 6.1L Hemi, 6.243 in. Length, Connecting Rod Set |
Weight Matched Set |
Yes |
Wrist Pin Journal Bushing Width |
1.000 |
Wrist Pin Style |
Floating |
Title - Web |
Chrysler, 5.7 / 6.1L Hemi, 6.243 in. Length, Connecting Rod Set |
Length |
4.0000 |
Width |
9.0000 |
Height |
12.0000 |
Weight |
12.0000 |
