Mag Force - These Clutches Are The Perfect Choice For Racers Looking For A Lightweight, High Torque Capacity Unit. They Are Designed To Be Used For Oval Track, Road Racing And Dry Lakes Applications. These Units Are Offered In Single Disc (500Ft Tq) Double Disc (900 Ft Tq) And Triple Disc (1500 Ft Tq) Configurations To Meet The Harshest Needs In The Industry. These Units Rely On A Pin Drive Actuation System Where The Floater Plate Slides On 6 Evenly Spaced Pins For Quick Release In A Racing Application. Our Mag Force Units Also Offer Bolt On External Balance Weights For Most Applications.
Specifications:
| Description_DES |
Mag Force: Triple Disc: Pin Drive: Ford: 1963-95 SBF: 1-1/8x26: 164T |
| Description_DEF |
Transmission Clutch Kit |
| Description_FAB |
The Mag Force is perfect for Road Racing, Drag Racing and Salt Flats Time trials. |
| Description_EXT |
Mag Force: Triple Disc: Pin Drive: Ford: 1963-95 SBF: 1-1/8x26: 164T |
| Description_INV |
Clutch Kit |
| Description_SHO |
Clutch Kit |
| Description_MKT |
Mag Force - These Clutches Are The Perfect Choice For Racers Looking For A Lightweight, High Torque Capacity Unit. They Are Designed To Be Used For Oval Track, Road Racing And Dry Lakes Applications. These Units Are Offered In Single Disc (500Ft Tq) Double Disc (900 Ft Tq) And Triple Disc (1500 Ft Tq) Configurations To Meet The Harshest Needs In The Industry. These Units Rely On A Pin Drive Actuation System Where The Floater Plate Slides On 6 Evenly Spaced Pins For Quick Release In A Racing Application. Our Mag Force Units Also Offer Bolt On External Balance Weights For Most Applications. |
| Flywheel Included |
Yes |
| Disc Diameter |
8In. |
| Pilot Bushing Material |
N/A |
| Disc Style |
Puck Style |
| Make |
Ford |
| Racing Application |
Road Race & Slalom Racing |
| Spline |
1 1/8In. x 26 |
| Balance |
For Ext Balanced Also Order Weight Kit 560222 |
| Alignment Tool Included |
Yes |
| Flywheel Material |
Aluminum |
| Number of Discs |
Triple |
| Hardware Included |
Yes |
| Throwout Bearing Included |
No |
| Disc Material |
Sintered Iron |
| Clutch Usage |
Drifting |
| Throwout Bearing Style |
Standard |
| Engine Balance |
Internal Balance |
| Pilot Bushing Included |
No |
| Ring Gear |
164 tooth |
| Engine |
1964-1995 SBF |
| Length |
6.0000 |
| Width |
17.0000 |
| Height |
16.0000 |
| Weight |
27.0000 |
