Intended for the high horsepower street/strip fan, the McLeod RXT 1200 street twin clutch kit is able to handle 1200hp. This clutch can handle almost any horsepower you can throw at it and still remain street-able. Ceramic lined clutch discs will provide smooth engagement with a moderate pedal effort to make this clutch kit ideal for the street/strip enthusiast. . This clutch is perfect for the person that wants the best of both worlds. You want to drive to the track then rip off a bunch of ┬╝ mile passes then drive back home, the RXT 1200 is what you'll need! This series of clutch comes in 3 different configurations to best suit your needs. Adapter ring version. Another McLeod Racing exclusive. We build a twin disc clutch using a patented approved adapter ring to bolt to your supplied flywheel. Complete unit with dedicated flywheel. No need to search for the clutch as one number and the flywheel as another number. McLeod Racing has you covered with one part number and a complete dedicated unit ready to plug and play. You have the choice of running a Billet Steel flywheel for your street applications or a Billet Aluminum flywheel for your track cars.
Specifications:
| Description_ASM |
Cadillac: CTS 04 - 05 5.7 L Engine, Cadillac: CTS 06 - 07 6 L Engine, Chevrolet: Camaro 98 - 02 5.7 L Engine, Chevrolet: Camaro 10 - 15 6.2 L Engine, Chevrolet: Camaro 14 - 15 7 L Engine, Chevrolet: Corvette 97 - 04 5.7 L Engine, Chevrolet: Corvette 05 - 07 6 L Engine, Chevrolet: Corvette 08 - 13 6.2 L Engine, Chevrolet: Corvette 06 - 13 7 L Engine, Chevrolet: SSR 05 - 06 6 L Engine, Pontiac: Firebird 98 - 02 5.7 L Engine, Pontiac: G8 09 - 09 6.2 L Engine, Pontiac: GTO 04 - 04 5.7 L Engine, Pontiac: GTO 05 - 06 6 L Engine |
| Description_DEF |
Transmission Clutch Kit |
| Description_EXT |
RXT1200: Steel Flywheel: Chevrolet: LS-X 6 Bolt Crank: 168T: 1-1/8x26 |
| Description_DES |
RXT1200: Steel Flywheel: Chevrolet: LS-X 6 Bolt Crank: 168T: 1-1/8x26 |
| Description_FAB |
McLeod Racing is the leader in twin disc clutch applications. We offer them in several different configurations to meet your needs. Give us a call 714-630-2764 to see what we can do for you! |
| Description_MKT |
Intended for the high horsepower street/strip fan, the McLeod RXT 1200 street twin clutch kit is able to handle 1200hp. This clutch can handle almost any horsepower you can throw at it and still remain street-able. Ceramic lined clutch discs will provide smooth engagement with a moderate pedal effort to make this clutch kit ideal for the street/strip enthusiast. . This clutch is perfect for the person that wants the best of both worlds. You want to drive to the track then rip off a bunch of ┬╝ mile passes then drive back home, the RXT 1200 is what you'll need! This series of clutch comes in 3 different configurations to best suit your needs. Adapter ring version. Another McLeod Racing exclusive. We build a twin disc clutch using a patented approved adapter ring to bolt to your supplied flywheel. Complete unit with dedicated flywheel. No need to search for the clutch as one number and the flywheel as another number. McLeod Racing has you covered with one part number and a complete dedicated unit ready to plug and play. You have the choice of running a Billet Steel flywheel for your street applications or a Billet Aluminum flywheel for your track cars. |
| Description_INV |
Clutch Kit |
| Description_SHO |
Clutch Kit |
| NOTE: |
2004-07 Cadillac CTS-V must purchase slave cylinder spacer 1377-950 (sold separately) |
| Throwout Bearing Style |
Hydraulic |
| Hub Style |
Solid |
| Number of Discs |
Double |
| Clutch Patterns |
RST/RXT Steel Adapter Plate Pattern |
| Spline |
1 1/8In. x 26 |
| Disc Style |
Segmented |
| Horsepower Rating |
1200 |
| Disc Diameter |
9-11/16In. |
| Hardware Included |
Yes |
| Make |
Chevrolet |
| Pilot Bushing Included |
No |
| Clutch Usage |
Street/Strip |
| Alignment Tool Included |
Yes |
| Flywheel Material |
Steel |
| Throwout Bearing Included |
No |
| Disc Material |
Ceramic |
| Pressure Plate Style |
Diaphragm |
| Pilot Bushing Material |
N/A |
| Flywheel Included |
Yes |
| Engine |
1997-2013 LS1/LS2/LS3/LS6/LS7 6 BOLT Crank |
| Ring Gear |
168 tooth |
| Length |
6.0000 |
| Width |
17.0000 |
| Height |
16.0000 |
| Weight |
48.0000 |
