The Edelbrock 1412 Performer Series 800 CFM manual choke carburetor is a precisely tuned, quality-built carburetor that can handle the rigors of daily driving while delivering consistent, reliable street performance from day to day. Several characteristics make the 1412 Performer Series 800 CFM manual choke carburetor an outstanding street performer. The first one is that metering rods are utilized to transition between circuits. The carburetor is unaffected by engine backfires, which means that there are no power valves to blow out, and the rods can be changed in seconds without carburetor removal or fuel draining. Secondly, the carburetor has the unique ability to "hold a tune", so once it is tuned, the carburetor stay's tuned. What this means to you is that compared to other carburetors, the performance remains consistent and the calibration stays unchanged. The lightweight all-aluminum body features a two-piece body that resists warping and is compatible with gasohol and blended fuels. The simple tub-type bowls and rear-pivot floats all contribute to a carburetor that's reliable, user-friendly and is easily tunable for miles and miles of trouble-free operation. Dyno tests proved that the EPS 800 carb outperformed a Holley #3310 carb out-of-the-box by 26 ft-lbs. of torque and 22 hp on a small-block Chevy engine equipped with an Edelbrock Performer RPM power package
Specifications:
| Description_ABR |
CARB |
| Description_DEF |
Carburetor |
| Description_EXT |
Edelbrock Performer Series EPS 800 cfm, Square-Bore, Manual Choke Carburetor (non-EGR) |
| Description_INV |
Edelbrock Performer 800 CFM Carburetor |
| Description_MKT |
The Edelbrock 1412 Performer Series 800 CFM manual choke carburetor is a precisely tuned, quality-built carburetor that can handle the rigors of daily driving while delivering consistent, reliable street performance from day to day. Several characteristics make the 1412 Performer Series 800 CFM manual choke carburetor an outstanding street performer. The first one is that metering rods are utilized to transition between circuits. The carburetor is unaffected by engine backfires, which means that there are no power valves to blow out, and the rods can be changed in seconds without carburetor removal or fuel draining. Secondly, the carburetor has the unique ability to "hold a tune", so once it is tuned, the carburetor stay's tuned. What this means to you is that compared to other carburetors, the performance remains consistent and the calibration stays unchanged. The lightweight all-aluminum body features a two-piece body that resists warping and is compatible with gasohol and blended fuels. The simple tub-type bowls and rear-pivot floats all contribute to a carburetor that's reliable, user-friendly and is easily tunable for miles and miles of trouble-free operation. Dyno tests proved that the EPS 800 carb outperformed a Holley #3310 carb out-of-the-box by 26 ft-lbs. of torque and 22 hp on a small-block Chevy engine equipped with an Edelbrock Performer RPM power package |
| Description_LAB |
Performer Carburetor #1412 800 CFM With Manual Choke, Satin Finish (Non-EGR) |
| Description_TRA |
Electric choke #1478 can be added if needed |
| Description_TRA |
Performer Series Carbs will work with Ford automatic overdrive trans (AOD) when used with Lokar bracket SRK-4000 |
| Description_TRA |
Edelbrock carburetors are not calibrated for or compatible with alcohol, race or E85 pump fuel. The use of alcohol or E85 in your Edelbrock carburetor will damage your carburetor and void your warranty. These fuels can also damage other fuel system components, unless specifically designed for use with alcohol fuels |
| Bore Diameter |
Primary Bore 1.75; Secondary Bore 1.75 |
| Choke Type |
Manual |
| Condition |
New |
| Secondary Jet Diameter |
0.101 |
| Metering Rod Size |
.071 x .047 |
| Spring Force |
5" Hg (Orange) |
| Gasket Or Seal Included |
Yes |
| RGL |
WARNING: This product can expose you to Zinc, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov. |
| Barrel Quantity |
4 Barrel |
| Booster Type |
annular |
| Main Venturi Diameter |
1.525 |
| Flange Shape |
Square |
| EGR Port |
No |
| Body Height |
3.25 |
| Finish |
Satin |
| Material |
Aluminum |
| Series |
Performer |
| Primary Jet Diameter |
0.113 |
| Maximum Flow Rating |
800 |
| Length |
7.0000 |
| Width |
7.0000 |
| Height |
13.0000 |
| Weight |
9.0000 |
